No. | BOM Code | Name | Model No. | Qty | Memo |
1 | 506.30.03120 | Cabinet | SW6308S-19-D-01-01 | 1 | |
2 | 506.30.03140 | Servo Motor Driver Mounting Pannel | SW6308S-19-D-01-03 | 1 | |
3 | 501.09.01001 | Buzzer | 24V | 1 | |
4 | 507.12.01015 | Wire Casing | W30*H80*L2000 | 1 | |
5 | 502.03.02016 | Panasonic 400WA6 Servo Motor Driver | MBDLN25SE | 3 | |
6 | 501.13.01001 | Absorber | CW4EL2-20A-T | 2 | |
7 | 505.08.06051 | Two Layers Terminal Seat | TBD-10 | 1 | |
8 | 501.16.01011 | Fencing | 9cm Fencing(MQ9225HBL2) | 2 | |
9 | 3.2176.02170 | Ground Wire Mount | SW6308S-19-D-01-08 | 1 | |
10 | 506.30.03150 | Cabinet Door | SW6308S-19-D-01-04 | 1 | |
11 | 506.30.03160 | Cabinet Door2 | SW6308S-19-D-01-05 | 1 | |
12 | 501.08.01006 | Tri-Colored Lamp | TPTL6-L3ROG-S | 1 | |
13 | 501.05.01009 | Relay Seat | PYF08A-E | 2 | |
14 | 501.15.01001 | Trapezoid Aluminum Shell Resistance | 100W40RJ | 3 | |
15 | 506.30.03180 | Brake Resistance Shield | SW6308S-19-D-01-07 | 1 | |
16 | 501.16.01001 | Fans | MQ9225HBL2 | 2 | |
17 | 502.01.05029 | Mother Board | 1630A(TB) | 1 | |
18 | 505.01.17001 | Copper Cylinder | M3*12+6 | 20 | |
19 | 502.01.05030 | IO Board | 1632A(TB)D-SUB180℃ | 1 | |
20 | 501.12.01002 | Contact | LC1D18M7C | 1 | |
21 | 506.30.03190 | PSU Mounting Pannel | SW6308S-19-D-01-09 | 1 | |
22 | 501.08.01016 | Schneider 2P10A Circuit Breaker | OSMC32N2C10 | 1 | |
23 | 506.30.03130 | Mother Board Mounting Plate | SW6308S-19-D-01-02 | 1 | |
24 | 501.05.01008 | Relay | TERXM2AB2BD-DC24V | 2 | |
25 | 501.10.01030 | PSU | LRS-50-24 | 3 | |
26 | 501.10.01032 | PSU | PMT-24V100W1AA | 1 | |
27 | 507.06.02001 | Cable Rack | KEL10/6 | 1 | |
28 | 507.06.02002 | Mini Cable Sealing Ring | KT4/6 | 1 | |
29 | 507.06.02004 | Mini Cable Sealing Ring | KT5 | 1 | |
30 | 507.06.02003 | Mini Cable Sealing Ring | KT2/7 | 3 | |
31 | 507.06.02005 | Mini Cable Sealing Ring | BTK | 1 | |
32 | 506.30.03170 | Power Breaker Mounting Seat | SW6308S-19-D-01-06 | 1 | |
33 | 501.16.01010 | Window Shades | Rectangular 802Filter(MQ9225HBL2) | 4 | |
34 | 506.30.03200 | Power Braker Mounting Rack | SW6308S-19-D-01-10 | 1 | |
35 | 506.21.01039B | HC Connector Convertor | HC-N-01B | 1 | |
36 | 501.04.01002 | Aviation Plug(Male) | WS28J16Z | 1 | |
37 | 507.06.01001 | Cable Gland | M-20K | 1 |
